2. SPECIFICATIONS
BAS-311HN, BAS-326H
2
2. SPECIFICATIONS
Sewing machine Lock stitch pattern tacking sewing machine
Stitch formation Single needle lock stitch
Max. sewing speed 2,800 sti/min
Max. sewing area (XxY) BAS-311HN: 150 x 100 mm BAS-326H: 220 x 100 mm
Feed mechanism Intermittent feed, pulse motor drive
Stitch length
0.05 − 12.7 mm
Maximum No. of stitches 20,000 stitches (per program)
No. of sewing data items
that can be stored
999 (Internal memory, SD card, USB memory) (*1)
Motor-driven work clamp specifications: Pulse motor drive method
Pneumatic work clamp specifications: Pneumatic cylinder method
Work clamp lift method
Motor-driven work clamp specifications: Integrated-type work clamp
Pneumatic work clamp specifications: Separate-type work clamp
Work clamp height
Motor-driven work clamp specifications: Max. 25 mm
Pneumatic work clamp specifications: Max. 30 mm
Intermittent presser foot lift
amount
22 mm
Intermittent presser foot
stroke
2 − 4.5 mm, 4.5 − 10 mm or 0 (Default setting 3 mm)
Hook Double-capacity shuttle hook
Wiper device Standard equipment
Thread trimmer Standard equipment
Cycle programs 30
Motor 550 W AC servo motor
Weights
Machine head Approx. 88 kg, LCD panel Approx. 0.8 kg
Control box 9 kg (Differs depending on destination)
Power source
Single-phase 110V / 220V / 230V, 3-phase 220V / 380V / 400V
(For single-phase 110 V and three-phase 380 V/400 V, the trans box is required.)
Air pressure 0.5 MPa 1.8 l/min.
(*1) The number of data items and stitches that can be stored will vary depending on the number of stitches in each
program.
No guarantees of operation can be given for any media.
3580B
