Brother HL-5450DN Technical Reference Guide

CHAPTER 2 PCL - 93
Byte
position
Data Description
0 - 1 6E 6E 'nn' This is header ID.
2 - 3 0A 00 Reserved
4 - 7 5E 00 00 00 Picture data start offset from header top
8 - 11 File length File length including 94 Byte header. If file length is 65,536 byte,
these 4 bytes become "00 00 01 00"
12 - 13 01 00 Reserved
14 - 15 01 00 Reserved
16 - 19 4A 00 00 00 Reserved
20 - 21 Compression mode 02 00: Fax MH format
03 00: Fax MR format
04 00: Fax G4 format
22 - 55 00 ... 00 All zero
56 - 59 Picture data length If picture data length is 65,442 (65,536 ~-94) byte, these 4 bytes
become "A2 FF 00 00."
60 - 61 01 00 bit / pixel
62 - 63 01 00 bit / pixel
64 - 65 Pixels/line If picture dot width = 2,400, these 2 bytes become "60 09"
66 - 67 Pixels/line Same as above.
68- 69 Lines/picture If picture dot count = 3,100, these 2 bytes become "1C 0C."
71 - 71 Lines/picture Same as above.
72 - 73 00 00 Reserved
74 - 75 Photometrics 00 00
or 01 00
00 00 : data 0 = white
01 00 : data 0 = black
76 - 77 02 00 Reserved
78 - 79 Fill order 01 00 or
02 00
01 00 : filled from MSB
02 00 : filled from LSB
80 - 81 01 00 Reserved
82 - 83 00 00 Reserved
84 - 85 01 00 Reserved
86 - 87 Resolution 200,
300, 400, 600
C8 00 00 00 : 200 dpi, 2C 01 00 00 : 300 dpi,
90 01 00 00 : 400 dpi, 58 02 00 00 : 600 dpi
400 and 600 dpi are available when the printer operates in 600 dpi
mode.
88 - 89 Resolution 200,
300, 400, 600
C8 00 00 00 : 200 dpi, 2C 01 00 00 : 300 dpi,
90 01 00 00 : 400 dpi, 58 02 00 00 : 600 dpi
400 and 600 dpi are available when the printer operates in 600 dpi
mode.
90 - 91 02 00 Reserved
92 - 93 00 00 Reserved
For further information about the CCITT G3/G4 data format, please refer to CCITT (The International
Telegraph and Telephone Consultative Committee) BLUE BOOK Volume VII.

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
