CHAPTER 2 PCL - 94
# = 1024 indicates TIFF format. This is valid only for 600 dpi data. The raster graphics data is transferred
with the ESC*b###W (### = data length) command. The TIFF file follows this mode set command. This
printer does not support LZW compression. Pages that contain TIFF data are printed in gray scale mode.
The TIFF data contains the header, tag and print data.
This mode supports TIFF Version 5.0 file format. In this mode, the transfer graphics data count does not
have a limitation of 32,767 bytes. This printer supports both "MM" (big endian) format and "II" (little
endian) format. The Print model is not applied to this type of data transfer. The printer has some limitations
on the TIFF format as follows:-
1. Tag position has to be prior to the picture (strip) data.
2. Compression tag - Tag ID : 259
The printer supports 1, 2, 3, 4 and 32773.
1 : no compression (Bits/Sample=1,4,8)
2 : CCITT G3 MH (Bits/Sample=1)
3 : CCITT G3 MR (Bits/Sample=1)
4 : CCITT G4 (Bits/Sample=1)
32773 : Pack Bits (Bits/Sample=1)
3. Sample/pixel - Tag ID : 277
This value should be 1. This means the printer accepts only monochrome TIFF files.
4. Bits/Sample - Tag ID: 258
The printer supports 1,4 and 8.
If you specify 4 or 8 and the printer resolution is 600 dpi, the printer prints the page using
APT.
5. Horizontal resolution (Tag ID=282) and Vertical resolution (Tag ID=283)
Compression type Bits/Sample Available Resolution APT
No Compression 4,8 From 1 dpi to 300 dpi ON
No Compression
Pack Bit
1 Printer's Resolution
(300 or 600 dpi)
OFF
CCITT G3 & G4 1 200,300,400,600 dpi
400 & 600 dpi are only available
when the printer operates in 600
dpi mode.
OFF
We recommend 150 dpi or less resolution for APT to reduce data size.
# = 1025 indicates the Brother original Compression Method.
# = 1026 indicates the Brother Advanced Data Transfer Mode.
