Brother MFC-7320 Service Manual

5-2
Confidential
1.3 List of Maintenance-mode Functions
Function Code Function Refer to:
01 EEPROM Parameter Initialization 1.4.1 (5-3)
05 Printout of Scanning Compensation Data 1.4.2 (5-4)
06 Placement of CIS Unit Position for Transportation 1.4.3 (5-6)
08 ADF Performance Test 1.4.4 (5-6)
09 Test Pattern 1.4.5 (5-7)
10 Worker Switch (WSW) Setting 1.4.6 [1] (5-9)
11 Printout of Worker Switch Data 1.4.6 [2] (5-12)
12 Operational Check of LCD 1.4.7 (5-13)
13 Operational Check of Control Panel Button 1.4.8 (5-14)
25 ROM Version Check 1.4.9 (5-15)
32 Operational Check of Sensors 1.4.10 (5-16)
43 PC print function setting (PCL PS) 1.4.11 (5-18)
53 Received Data Transfer Function 1.4.12 (5-22)
54 Fine Adjustment of Scan Start/End Positions 1.4.13 (5-24)
55 Acquisition of White Level Data 1.4.14 (5-26)
67 Paper Feeding and Ejecting Test 1.4.15 (5-26)
74 EEPROM Customizing 1.4.16 (5-27)
78 Operational Check of Fans 1.4.17 (5-29)
80 Display of the Machine's Log 1.4.18 (5-31)
82 Error Code Indication 1.4.19 (5-33)
87 Output of Transmission Log to the Telephone Line 1.4.20 (5-33)
91 EEPROM Parameter Initialization 1.4.1 (5-3)
99 Exit from the Maintenance Mode 1.4.21 (5-34)
* The functions shaded in the table above are user-accessible.

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
