Brother MFC-7320 Service Manual

App. 1-1
Confidential
APPENDIX 1 WORKER SWITCH Settings (WSW)
This appendix describes the functions of the Worker switches, which can be divided into two
groups: one is for customizing preferences designed for the shipping destination (Refer to
"1.4.16 EEPROM Customizing (Function code 74)" in Chapter 5) and the other is for
modifying preferences that match the machine to the environmental conditions. Use the latter
group if the machine malfunctions due to mismatching.
Each switch has eight selectors. However, some of them cannot be set by an end user. Only
selectors in the worker switch setting tables of this Appendix that are shaded can be set by
an end user.
The worker switch setting procedure is described in Chapter 5, Section 1.4.6 [ 1 ] Worker
Switch Setting (Function code 10).
■ Worker Switch
WSW No. Function Refer to:
WSW01 Dial pulse setting App. 1-3
WSW02 Tone signal setting App. 1-5
WSW03 PABX mode setting App. 1-6
WSW04 Transfer facility setting App. 1-8
WSW05 1st dial tone and busy tone detection App. 1-9
WSW06 Redial/Pause button setting and 2nd dial tone detection App. 1-10
WSW07 Dial tone setting 1 App. 1-12
WSW08 Dial tone setting 2 App. 1-13
WSW09 Protocol definition 1 App. 1-14
WSW10 Protocol definition 2 App. 1-15
WSW11 Busy tone setting App. 1-16
WSW12 Signal detection condition setting App. 1-17
WSW13 Modem setting App. 1-18
WSW14 AUTO ANS facility setting App. 1-19
WSW15 Redial facility setting App. 1-20
WSW16 Function setting 1 App. 1-21
WSW17 Function setting 2 App. 1-22
WSW18 Function setting 3 App. 1-23
WSW19 Transmission speed setting App. 1-24
WSW20 Overseas communications mode setting App. 1-25
WSW21 TAD setting 1 App. 1-26
WSW22 ECM and call waiting caller ID App. 1-27
WSW23 Communications setting App. 1-28
WSW24 TAD setting 2 App. 1-29
WSW25 TAD setting 3 App. 1-30
WSW26 Function setting 4 App. 1-31
WSW27 Function setting 5 App. 1-32

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
