Brother MFC-7320 Service Manual

5-31
Confidential
1.4.18 Display of the Machine's Log Information (Function code 80)
<Function>
The machine may display its log information on the LCD.
<Operating Procedure>
(1) MFC7840W/7840N/7450/7440N/7340/7320
Press in order the 8 and 0 buttons in the initial stage of the maintenance mode.
The USB serial number appears on the LCD.
DCP7045N/7040/7030
Press the or button. "MAINTENANCE 80" appears on the LCD, and then press the
OK button.
(2) Each time the Start button is pressed, one of the following log information items appears
on the LCD in the order. The representative items are given below.
(3) Press the Stop/Exit button so that the machine stops this operation, beeps for one
second and returns to the initial stage of the maintenance mode.
Note :
If the OK button is pressed when the "MACHINE ERR" or "COMEER1" appears on the LCD,
the date and time when the error occurs are indicated on the LCD.
USB: Serial number
DRUM: Drum count
COVERAGE: Average Coverage (%) *
1
TTL_PG: Total number of printed pages
COPY: Number of copies made
PCPRINT: Number of PC prints made
FAX: Number of FAX outputs made *
2
LIST: Number of list page printed pages
TR1_PG: Number of pages picked up from the T1.
MN_PAGE: Number of pages picked up from manual tray.
A4+LTR: Number of A4/Letter size sheets picked up.
LG+A4L: Number of LEGAL/A4 LONG size sheets picked up.
B5+EXE: Number of B5/Executive size sheets picked up.
ENVLOP: Number of envelopes picked up.
A5 Number of A5 size sheets picked up.
OTHER: Number of other-size sheets picked up.
PLTNRE: Number of Plain/Thin/Recycled sheets made.
TRANSP: Number of Transparency mode.
TKTRBD: Number of Thick/Thicker/Bond made.
ENVLOP: Number of Envelop/Env. Thick/Env. Thin made.
TTL_JAM: Total number of jams
TR1_JAM Number of jams that occurred at the T1.
MN_JAM Number of jams that occurred at the manual tray.
IN_JAM Number of jams that occurred inside the machine.
