Brother MFC-7320 Service Manual

1-57
Confidential
12. OTHERS PROBLEMS
■ The machine is not turned on, or the LCD indication does not appear.
■ The fan does not work.
Step Cause Check Result Remedy
1
Harness
connection
failure of panel
PCB
Is the harness of the
panel PCB ASSY
connected correctly?
No
Reconnect the panel PCB
ASSY harness.
2
Panel PCB
failure
Is the problem solved
after replacing the panel
PCB ASSY?
Ye s
Replace the panel PCB
ASSY.
3
LCD failure Is the problem solved
after replacing the LCD?
Ye s
Replace the LCD.
4
LVPS PCB failure Is the problem solved
after replacing the LVPS
PCB unit?
Ye s
Replace the LVPS PCB
unit.
5
Main PCB failure Is the problem solved
after replacing the main
PCB ASSY?
Ye s
Replace the main PCB
ASSY.
Step Cause Check
Result Remedy
1
Harness
connection
failure of the fan
motor 60 ASSY.
Is the harness of the fan
motor 60 ASSY
connected correctly?
No
Reconnect the harness of
the fan motor 60 ASSY
correctly.
2
Toner LED PCB
ASSY failure
Is the problem solved
after replacing the toner
LED PCB ASSY?
Ye s
Replace the toner LED
PCB ASSY.
3
Main PCB failure Is the problem solved
after replacing the main
PCB ASSY?
Ye s
Replace the main PCB
ASSY.

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
