Brother MFC-7320 Service Manual

5-33
Confidential
1.4.19 Error Code Indication (Function code 82)
<Function>
This function displays an error code of the machine on the LCD.
<Operating Procedure>
(1) MFC7840W/7840N/7450/7440N/7340/7320
Press in order the 8 and 2 buttons in the initial stage of the maintenance mode.
DCP7045N/7040/7030
Press the or button. "MAINTENANCE 82" appears on the LCD, and then press the
OK button.
The machine displays "MACHINE ERROR X
X" on the LCD.
(Refer to "2. ERROR CAUSE" in Chapter 1.)
(2) Press the Stop/Exit button. The machine beeps for one second and returns to the initial
stage of the maintenance mode.
1.4.20 Output of Transmission Log to the Telephone Line (Function code 87)
(only MFC7840W/7840N/7450/7440N/7340/7320)
<Function>
This function outputs the transmission log (that the machine has stored about the latest
transmission) to the telephone line. It allows the service personnel to receive the
transmission log of the user's machine at a remote location and use it for analyzing problems
arising in the user's machine.
<Operating Procedure>
(1) If the user's machine has a transmission-related problem, call the user's machine at a
remote location from your machine.
(2) If the line is connected, have the user perform the following:
1) Hook up to the external phone.
2) Press in order the Menu, Start, Menu buttons.
3) Press the 8 and 7 buttons.
The above operation makes the user's machine send CNG to your machine for
sending the transmission log.
(3) If you hear the CNG sent from the user's machine, press the Start button of your
machine.
Your machine will start to receive the transmission log from the user's machine.

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
