Brother MFC-7320 Service Manual

App. 1-31
Confidential
<WSW26>
• Selector 3: Dialing during document reading into the temporary memory in in-
memory message transmission
If this selector is set to "0," the machine waits for document reading into the memory to
complete and then starts dialing. This enables the machine to list the total number of
pages in the header of the facsimile message.
• Selectors 4 and 5: No. of CNG cycles to be detected (when the line is connected via
the external telephone except in the external TAD mode or via the
built-in telephone)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of
cycles specified by these selectors when the line is connected via the external telephone
except in the external TAD mode or via the built-in telephone.
• Selectors 6 and 7: No. of CNG cycles to be detected (when the line is connected via
the external telephone in the external TAD mode, via the built-in
telephone in the TAD mode, or via the machine in the automatic
reception of the F/T mode)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of
cycles specified by these selectors when the line is connected via the external telephone in
the external TAD mode, via the built-in telephone in the TAD mode, or via the machine in
the automatic reception of the F/T mode.
Selector No. Function Setting and Specifications
1
2
Not used.
3
Dialing during document reading
into the temporary memory in in-
memory message transmission
0: Disable 1: Enable
4
5
No. of CNG cycles to be detected
(when the line is connected via
the external telephone except in
the external TAD mode or via the
built-in telephone)
No. 4 5
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
The number of
times changes by
the selector 3 of the
WSW54.
(Refer to " WSW54"
Selector 3)
6
7
No. of CNG cycles to be detected
(when the line is connected via
the external telephone in the
external TAD mode, via the built-in
telephone in the TAD mode, or via
the machine in the automatic
reception of the F/T mode)
No. 6 7
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
8 Not used.

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
