Brother MFC-7320 Service Manual

App. 1-59
Confidential
<WSW54>
Note:
• Selectors 1 and 2 are applicable only to models equipped with PictBridge.
• Selector 4 is applicable only to models equipped with cordless handset(s).
• Selectors 5 through 7 are applicable only to models designed for the UK market.
• Selector 8 is applicable only to models designed for the Chinese market.
• Selector 1 and 2: PictBridge command delay time (Not used)
These selectors specify the PictBridge command delay time that applies when the machine
responds to the digital camera connected via PictBridge during negotiation. If the machine
fails to receive data from the digital camera, change the delay time.
• Selector 3: More CNG detection cycles in user-friendly reception
If CNG detection fails even after adjustment of selectors 4 and 5 on WSW26, try adding 2
more cycles to the permitted number of CNG detection cycles.
• Selector 4: Cordless handset ID recovery (Not used)
When this function becomes operative, if the cordless handset ID number registered on the
main board does not match that registered on the cordless board, the cordless handset ID
number registered on the main board will be automatically written onto the cordless board.
• Selectors 5 and 6: Caller ID tone alert detection time length
In the event of a false detection of a caller ID tone alert, adjust the detection time length.
• Selector 7: Caller ID mild pulse transmission (Not used.)
If a caller ID (number display) cannot be displayed due to mild pulses transmitted after
detection of tone alert, use this selector so as to make it impossible to transmit mild pulses.
Selector No. Function Setting and Specifications
1
2
PictBridge command delay time
(Not used.)
No. 1 2
0 0: 100 ms (default)
01: 0 ms
1 0: 50 ms
1 1: 200 ms
3
More CNG detection cycles in
user-friendly reception
0: No 1: 2 more cycles
4
Cordless handset ID recovery
future (Not used.)
0: Valid 1: Invalid
5
6
Caller ID tone alert detection
time length
No. 5 6
0 0: 50 ms (default)
0 1: 60 ms
1 0: 70 ms
1 1: 80 ms
7
Caller ID mild pulse
transmission (Not used.)
0: Yes 1: No
(default)
8
Switching between DTMF and
FSK for caller ID reception (Not
used.)
0: DTMF 1: FSK
(default)

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
