• Selectors 1 through 3: Redial/Pause button setting and 2nd dial tone detection
• Selectors 4 through 6: Detection of international tone
Upon detection of the 2nd dial tone for the time length specified by these selectors, the
machine starts dialing.
This setting is effective only when the 2nd dial tone detection function is activated by
selectors 1 through 3 (Setting 101, 110, or 111).
This function does not apply in those countries where no dial tone detection function is
supported.
• Selector 7: No. of 2nd dial tone detection cycles
This selector sets the number of dial tone detection cycles required for starting dialing.
• Selector 8: Allowable instantaneous interrupt during reception of 2nd dial tone
This selector sets the allowable instantaneous interrupt period that should be ignored
during reception of the 2nd dial tone.
Selectors
1 2 3
0 0 0 No wait is inserted even if the Redial/Pause button is pressed.
0 0 1
0 1 0
0 1 1
1 0 0
If you press the Redial/Pause button during dialing, the machine will
insert wait as defined in the above table.
If the Redial/Pause button is pressed repeatedly, the machine inserts
the specified wait multiplied by the number of depressions. It applies
also in hook-up dialing.
1 0 1
1 1 0
1 1 1
When these selectors are set to "1, 0, 1":
Each time you press the Redial/Pause button in dialing, the machine
will wait for the 2nd dial tone to be sent via the communications line
regardless of pulse dialing or tone dialing.
When these selectors are set to "1, 1, 0":
If you press the Redial/Pause button in pulse dialing, the machine will
first wait for the 2nd dial tone to be sent via the communications line.
After that, pressing the Redial/Pause button will cause the machine to
insert a WAIT of 3.5 seconds. In tone dialing, the machine will insert a
WAIT of 3.5 seconds.
When these selectors are set to "1, 1, 1":
If you press the Redial/Pause button, the machine will first wait for the
2nd dial tone to be sent via the communications line regardless of pulse
dialing or tone dialing. After that, pressing the Redial/Pause button will
cause the machine to insert a wait of 3.5 seconds.
((In those countries where no dial tone detection function is supported,
setting these selectors to "1, 0, 1," "1, 1, 0," or "1, 1, 1" inserts a wait of
3.5 seconds.)

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
