Brother MFC-7320 Service Manual

App. 1-34
Confidential
<WSW29>
Note:
• Selectors 1 through 6 are applicable to models equipped with built-in TADs.
• Selectors 7 and 8 are applicable only to the European versions.
• Selectors 1 through 6:Compression threshold level for voice signals inputted via the
telephone line and handset in the built-in TAD operation (Not
used.)
If voice signals inputted via the telephone line are below the level specified by these
selectors, the TAD interprets those received voice signals as no signal, compressing the
recording time.
• Selector 8: Prompt beep for activity report (Not used.)
This selector determines whether or not to beep if the memory area for the activity report
becomes full, for prompting you to print out the report. (Printing it out will clear the memory
area.)
Selector No. Function Setting and Specifications
1
I
3
Compression threshold level for
voice signals inputted via the
telephone line in the built-in TAD
operation (Not used.)
No. 1 2 3
0 0 0: -47.0 dBm (A)
0 0 1: -48.5 dBm (B)
0 1 0: -50.0 dBm (C)
0 1 1: -51.5 dBm (D)
1 0 0: -53.0 dBm (E)
1 0 1: -54.5 dBm (F)
1 1 0: -56.0 dBm (G)
1 1 1: OFF (H)
4
I
6
Compression threshold level for
voice signals inputted via the
handset in the built-in TAD
operation (Not used.)
No. 4 5 6
0 0 0: -44.0 dBm (A)
0 0 1: -45.5 dBm (B)
0 1 0: -47.0 dBm (C)
0 1 1: -48.5 dBm (D)
1 0 0: -50.0 dBm (E)
1 0 1: -51.5 dBm (F)
1 1 0: -53.0 dBm (G)
1 1 1: OFF (H)
7
Impedance switching control in
pulse dialing (Not used.)
0: OFF 1: ON
8
Prompt beep when the memory
area for the activity report
becomes full (Not used.)
0: No 1: Yes

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
