Brother MFC-7320 Service Manual

App. 1-52
Confidential
<WSW47>
Note:
• Selector 1 is applicable only to models equipped with flat-bed scanners.
• Selectors 3 and 4 are applicable only to models supporting pseudo-ringing of a connected
external telephone.
• Selector 1: Handling paper at the occurrence of a paper feed timing error (Not used.)
When feeding paper to the print start position, the machine might cause a feed timing error
so that the registration sensor goes ON signaling the presence of paper. This selector
determines whether the machine prints on the current paper or ejects the current paper
without printing and prints on the next paper.
• Selectors 3 and 4: Delay of FAX line disconnection when switching to the pseudo-
ringing external telephone (Not used.)
When the machine receives a phone call, it can make the connected external telephone
ring (so called pseudo-ringing). During pseudo-ringing, if you pick up the handset of the
external telephone, the line might be disconnected due to cut-off of the line current. To hold
the line, the machine may supply line current by making use of the pulse generator circuit
that forms a parallel loop. This way the FAX line disconnection may be delayed. These
selectors determine the delay period.
Selector No. Function Setting and Specifications
1
Handling paper at the
occurrence of a paper feed
timing error (Not used.)
0: Eject paper w/o print
1: Print on the current paper
2 Not used.
3
4
Delay of FAX line disconnection
when switching to the pseudo-
ringing external telephone
(Not used.)
No. 3 4
0 0: 200 ms
0 1: 400 ms
1 0: 700 ms
1 1: 1000 ms
5
Disable the ringer of external
telephone at non-ring reception
(Not used.)
0: No 1: Yes
6 Not used.
7
Disable the ringer of external
telephone with CAR signal when
caller ID service is available (Not
used.)
0: No 1: Yes
8
Switching between high-speed
USB and full-speed USB
0: Auto switching between high-speed
USB (ver. 2.0) and full-speed USB
(ver. 1.1)
1: Fixed to full-speed USB (ver. 1.1)

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
