Brother MFC-9840CDW User Manual

Dialing and storing numbers
61
8
e Choose one of the options below:
 Enter the name using the dial pad
(up to 15 characters). Press OK.
 Press OK to store the number or
E-mail address without a name.
f If you want to save a fax/scan resolution
along with the number, choose one of
the options below:
 If you selected Fax/Tel in c, press
a or b to select Std, Fine, S.Fine
or Photo.
Press OK and then go to h .
 If you selected E-Mail in c, press a
or b to select B/W200dpi,
B/W200x100, Color150dpi,
Color300dpi or Color600dpi.
Press OK and then go to g .
 If you selected IFAX in c, press a or
b to select Std, Fine or Photo.
Press OK and then go to h .
 Press OK if you don’t want to change
the default resolution. Go to h.
g If you selected Black & White in f,
select the file format (TIFF or PDF) that
will be used to send to your PC. If you
selected Color in f, select the file
format (PDF or JPEG) that will be used
to send your PC.
Press OK
h Choose one of the options below:
 To store another Speed-Dial number
go to b.
 To finish storing Speed-Dial
numbers press Stop/Exit.
Note
When you do a broadcast and you have
saved a scan profile along with the
number or E-mail address, the scan profile
of the One-Touch, Speed-Dial or Group
number you chose first will be applied to
the broadcast.
Changing one-touch and
speed-dial numbers 8
If you try to store a One-Touch or Speed-Dial
number over an existing number, the LCD will
show the name or number already stored
there.
a Do one of the following:
 To change the stored number,
press 1.
 To exit without making a change,
press 2.
23.Set Quick-Dial
#005:MIKE
a 1.Change
b 2.Exit
Select ab or OK
b Press a or b to select Fax/Tel, E-Mail
or IFAX. Press OK.
c Enter a new number or character.
Press OK.
d Press d or c to position the cursor under
the character you want to change, and
then press Clear/Back to delete it.
Repeat for each character you want to
delete.
e Follow the directions beginning in f in
Storing one-touch dial numbers and
Storing Speed-Dial numbers. (See
Storing one-touch dial
numbers on page 59 and Storing
speed-dial numbers on page 60.)

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
