Scanning
49
2
Pre-Scanning and cropping a portion using the scanner glass 2
The Preview button is used to preview an image for cropping any unwanted portions from the image. When
you are satisfied with the preview, click the Scan button in the Scan dialog box to scan the image.
a Follow the steps from a to e of Scanning a document into the PC on page 47.
b Put the document face down on the scanner glass.
c Choose Flatbed in the Source drop-down list. Adjust the following settings, if needed, in the Scanner
dialog box.
1 Profile
2 Source
3 Color format
4Filetype
5 Resolution
6 Brightness
7 Contrast
8 Scanning area
If your machine has no Auto Document Feeder (ADF), you do not need to specify the Source.
d Click Preview.
The whole image is scanned into the PC and appears in the scanning area (8).
1
2
3
4
5
6
7
8
