42
WSW42
(Function setting 18)
Selector
No.
Function Setting and Specifications
1 Incoming mail server POP*
1
0: OFF 1: ON
2 Incoming mail server SMTP*
2
0: OFF 1: ON
3 Internet-FAX forward function 0: OFF 1: ON
4JBIG*
3
coding system 0: Disabled 1: Enabled
5
|
8
Not used.
*
1
POP: Post Office Protocol
*
2
SMTP: Simple Mail Transfer Protocol
*
3
JBIG: Joint Bi-level Image Group
NOTE: Selectors 1 through 3 are applicable to those models equipped with LAN interface.
 Selector 3: Internet-FAX forward function
If this selector is set to "ON," the machine may forward a FAX message received through Internet
to other remote G3 facsimile machine.
WSW43 (Function setting 19)
Selector
No.
Function Setting and Specifications
1
Not used.
2
3
Wait time for PCFax reception
(Class 2) and FPTS command
transmission
No. 2 3
0 0 : 50 ms
0 1 : 100 ms
1 0 : 150 ms
11 : 0 ms
4
5
Detection time of 2100 Hz CED or
ANSam
No. 4 5
0 0 : 200 ms
0 1 : 300 ms
1 0 : 400 ms
1 1 : 500 ms
6
|
8
Not used.
