Brother NX-2000 - Retrieving Stitch Patterns from the Computer

USING THE MEMORY FUNCTION
Character/Decorative Stitches
123
4
c
Press .
* Press to delete the stitch pattern.
→ The selected stitch pattern is retrieved and the
sewing screen appears.
Retrieving Stitch Patterns from the
Computer
a
Plug the USB cable connectors into the
corresponding USB ports on the computer
and on the machine (see page 121).
b
On the computer, open “My Computer”, and
then go to “Removable Disk”.
c
Move/copy the pattern data to “Removable
Disk”.
→ Stitch pattern data in “Removable Disk” is written to
the machine.
d
Press .
→ The stitch patterns in the computer are displayed in
the selection screen.
Memo
A maximum of 24 stitch patterns or 476 KB can be
moved or copied to “Removable Disk”.
Note
• While data is being written, do not disconnect the
USB cable.
• Do not create folders within “Removable Disk”.
Since folders are not displayed, stitch pattern data
within folders cannot be retrieved.
