Brother NX-2000 User Manual

SEWING THE STITCHES
Utility Stitches
67
3
■ Overcasting Using the Optional Side Cutter
By using the side cutter, you can do overcasting while cutting the fabric.
a
Follow the steps on page 32 to remove the
presser foot.
b
Position the fork on the side cutter’s
operating lever onto the needle clamp screw.
a Needle clamp screw
b Operating lever
c
Position the side cutter so that the side cutter
pin is aligned with the notch in the presser
foot holder, and then lower the presser foot.
a Notch in presser foot holder
b Pin
→ The side cutter is attached.
CAUTION
• Make sure to only select one of the stitches listed below. Using another stitch may cause the needle to hit the presser
foot and break, possibly causing injury.
Memo
Thread the needle manually when using the side cutter, or only attach the side cutter after threading the needle using the
needle threader.
Stitch
Key
Stitch name
Presser
foot
Applications
Stitch width
[mm (inch)]
Stitch length
[mm (inch)]
Twin
Needle
Auto Manual Auto Manual
With side cutter
Straight stitch while cutting
fabrics
0.0
(0)
0.0 - 2.5
(0 - 3/32)
2.5
(3/32)
0.2 - 5.0
(1/64 - 3/16)
NO
With side cutter
Zigzag stitch while cutting fabrics
3.5
(1/8)
3.5 - 5.0
(1/8 - 3/16)
1.4
(1/16)
0.0 - 4.0
(0 - 3/16)
NO
With side cutter
Overcasting stitch while cutting
fabrics
3.5
(1/8)
3.5 - 5.0
(1/8 - 3/16)
2.0
(1/16)
1.0 - 4.0
(1/16 - 3/16)
NO
With side cutter
Overcasting stitch while cutting
fabrics
5.0
(3/16)
3.5 - 5.0
(1/8 - 3/16)
2.5
(3/32)
1.0 - 4.0
(1/16 - 3/16)
NO
With side cutter
Overcasting stitch while cutting
fabrics
5.0
(3/16)
3.5 - 5.0
(1/8 - 3/16)
2.5
(3/32)
1.0 - 4.0
(1/16 - 3/16)
NO
Memo
Make sure that the fork of the operating lever is set
onto the needle clamp screw firmly.
a
b
a
b
