30
For network interface cable users
(Manual network configuration)
9
For Mac OS
®
X 10.3.9
Click [Add] and choose IP Printing at the
top of the screen.
Enter the IP address of the printer into the
Printer Address box. Choose “PT-
9800PCN” from the list and click [Add]
again to add the printer to the “Printer
Setup Utility”.
For Mac OS
®
X 10.4.x - 10.6
Click [Add] and choose IP Printer / IP at
the top of the screen.
Enter the IP address of the printer into the
Address box. Choose “Brother PT-
9800PCN” from the list and click [Add]
again to add the printer to the “Printer
Setup Utility”.
0
When the screen returns to “Printer List”
/ “Print & Fax” screen, check that
“Brother PT-9800PCN” is added, and
close the “Printer List” / “Print & Fax”
screen.
Now you can use the printer.
Installing the BRAdmin Light
configuration utility
The BRAdmin Light is a utility for initial setup
of Brother network connected devices. It can
also search for Brother products on your
network, view the status and configure basic
network settings, such as IP address.
For more information on BRAdmin Light, visit
us at http://solutions.brother.com/
1
Double click “BRAdmin Light.pkg” in the
“Mac OS X” folder.
The BRAdmin Light Installer starts up.
Follow the on-screen instructions.
2
When the installation is completed and
the message “The Software was
successfully installed.” is displayed, click
[Close].
The installation of BRAdmin Light is
completed.
Note
When specifying the Queue Name, use
the value BRNxxxxxxxxxxxx at where
xxxxxxxxxxxx is the Ethernet address.
Note
For details on software, see the P-touch
Editor Help.
Note
If you are using Personal Firewall
software, BRAdmin Light may fail to
detect the unconfigured device. In that
case, disable your Personal Firewall
software, try BRAdmin Light again. Re-
start your Personal Firewall software after
the address information is set.
PT9700PC9800PCN_US.book Page 30 Wednesday, October 7, 2009 11:58 AM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother P-touch PT-9700PC and is the answer not in the manual?

Brother P-touch PT-9700PC Specifications

General IconGeneral
Print technologyDirect thermal
Vertical printingYes
Maximum resolution720 x 360 DPI
Product colorWhite
Keyboard layoutABC
Standard interfacesUSB 2.0
USB 2.0 ports quantity1
Minimum storage drive space70 MB
Compatible operating systemsMicrosoft Windows 2000 Prof. (SP4), XP, Vista, Windows 7, Mac OS X 10.4 - 10.6
Tape size36 mm
Label typeTZ / AL / HZ
Power supply typeAC adaptor (AD9100ES) (Enclosed)
Print sizes included20
Maximum label length1 m
Tape cuttingAutomatic
Number of styles10
Built-in barcodesPOSTNET, UPC-A, UPC-E
Bundled softwareP-touch Editor 5.0
Package weight3.190 g
Weight and Dimensions IconWeight and Dimensions
Depth193 mm
Width116 mm
Height140 mm
