Brother P-touch PT-9700PC User Manual

48
I do not understand how to install the
second printer that I have purchased.
• With a USB connection
When the printer is connected to the computer using a USB
cable, the driver for the second printer is automatically
installed through Plug and Play.
• With a Peer-to-Peer connection (PT-9800PCN only)
- If one is already installed
After the second printer is connected to the LAN, the
installer starts up and the printer driver is installed. Both
printers are listed in the dialog box where the printer can be
selected. Identify the second printer by its IP address, and
then select it. The selected printer driver is registered with
the computer.
- If multiple printers are to be installed at the same time
When the printers are connected to the LAN, the installer
starts up and the printer drivers are installed. If multiple
printers are selected in the list appearing in the dialog box
where printers are selected, the selected printer drivers are
registered with the computer.
I do not understand how to share a printer
on a network (PT-9800PCN only).
See “Network User’s Guide” (PDF).
Problem Solution
PT9700PC9800PCN_US.book Page 48 Wednesday, October 7, 2009 11:58 AM

Brother P-touch PT-9700PC Specifications

General

Print technology	Direct thermal
Vertical printing	Yes
Maximum resolution	720 x 360 DPI
Product color	White
Keyboard layout	ABC
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Minimum storage drive space	70 MB
Compatible operating systems	Microsoft Windows 2000 Prof. (SP4), XP, Vista, Windows 7, Mac OS X 10.4 - 10.6
Tape size	36 mm
Label type	TZ / AL / HZ
Power supply type	AC adaptor (AD9100ES) (Enclosed)
Print sizes included	20
Maximum label length	1 m
Tape cutting	Automatic
Number of styles	10
Built-in barcodes	POSTNET, UPC-A, UPC-E
Bundled software	P-touch Editor 5.0
Package weight	3.190 g

Weight and Dimensions

Depth	193 mm
Width	116 mm
Height	140 mm
