PRIMARY CONTROLS
rmo2010-001-038_n
1. Parking brake switch
NOTE: To apply or release the parking
brake, the ignition key must be turned
ON.
NOTE: The battery voltage must be at
10.5 V minimum to activate the parking
brake. If voltage is below 10.5 V, the
parking brake indicator lamp will turn
ON.
Applying Parking Brake
With the vehicle stopped, press switch
to apply the parking brake. The brake
indicator lamp will flash.
rmo2010-001-038_b
1. Press here
NOTE: The parking brake cannot be
activated when the vehicle is above
10 km/h (6 MPH).
Check that the parking brake is fully en-
gaged. Hold the clutch (on SM5 mod-
els) and rock the vehicle back and forth.
Releasing Parking Brake
To release parking brake, press and re-
lease switch and make sure brake in
di-
cator lamp turns OFF.
rmo2010-001-038_b
1. Press here
_______________
15
