SECONDARY CONTROLS
rmo2010-001-039_a
1
Ignition switch 8 Horn button
2 Engine start button 9 Windshield adjustment button
3 Enginestopswitch 10
RECC (Roadster Electronic Command Center)
4
Hazard warning switch
11
Reverse button
5
Cruise control switch
12 PTT (Push To Talk) button
6 Headlight switch 13
Switch cluster
7
Turn signal button
1) Ignition Switch
rmo2008-001-002_a
IGNITION SWITCH
1. OFF
2. ON
3. Front storage compartment opening
4. Seat opening/fuel tank access
5. Steering/glove box lock position
The ignition switch is located in the
center of the handlebar. It controls:
– Engine ignition
– Seat opening mechanism to access:
• Fuel tank cap
• Brake fluid reservoirs.
– Front storage compartment open-
ing mechanism to access:
• Fuses
• Battery terminals.
– Steering/glove box lock mecha-
nism.
NOTICE
If the key does not turn
easily, do not force it. Pull it out and
reinsert.
16
