Bruker BSMS/2 User Manual

Power Supply Modules
22 Bruker
BSMS/2 Mainframe Version 001
Table 5. Non-Regulated Voltages
(Mains voltage: 230VAC, Primary Voltage Selection Switch Position: 220-245 )
Vo l ta g e
Name
Reference point
Voltage at
rated load
Current at
rated load
Voltage ripple
(mV)
VPWR_P1 VPWR_GND1 20 - 24 V 3.5 A 800
VPWR_N1 VPWR_GND1 20 - 24 V 3.5 A 800
VPWR_P2 VPWR_GND2 20 - 25 V 6.0 A 1000
VPWR-N2 VPWR_GND2 20 - 25 V 6.0 A 1000
HE_P HE_GND 35 - 42 V 0.4 A 1000
PNEU_24V PNEU_GND 21 - 27 V 1.0 A 1500
X10V X10VGND 8.5 - 11.5 V 1.5 A 800
