Brusa DMC524 - Cooling Water Connections

51
Technical data
and startup
8.6 Cooling water connections
INFORMATION
The cooling water hose gets attached to the Normaquick terminals (1) and (2). Optionaly, you can
order normal cooling water connections for hose clamps, see chapter 4.4 Optional delivery contents.
The Normaquick connections have an inner diameter of 11 mm.
Cooling water inlet (1)
Cooling water outlet (2)
