10.1 Build connection between CVI and the inverter
PROCEDURE STEP
ILLUSTRATION / OTHER INFORMATION
1.
Switch on the inverter.
Activate terminal 15 in addition to terminal 30.
The status Rx (9) will then flash.
2.
Click the button GO (1).
The CAN connection is activated.
Both statuses Tx and Rx (9) should light up green.
3.
Click the button Clear Error latch (15).
Errors in the queue are deleted.
The button Clear Error latch (15) should now be dark.
The LED Ready (16) should now light up green.
All error statuses in the area (5) should be dark.
4.
Select the desired mode with the selector
switch (18).
Torque Mode or Speed Mode.
5.
Set the DC limits (10), (11), (12), (13) and check the
set values.
---
6.
Enter the desired speed (20) and the desired
torque (19).
---
INFORMATION
If no limitation is active, the motor will attempt to reach the entered value immediately! If there is no
load on the drive side, the motor accelerates until it reached the maximum speed!
7.
Click the button Command Enable (15).
The motor runs at the value set previously (speed or
torque).
The target values can now be read in the section (14)
as well as on the rpm counter (4) and the meter (3).
Limitations can be changed during operation in
sections (10) to (13). These have a direct impact on
operation.
10.2 Disconnect the communication between CVI and the inverter / Switch off the
inverter
For the disconnection an existing connection, there are other possibilities. These are as follows:
Click the button STOP (8).
Click the button Command Enable (15).
Press the button ESC on the operating keypad.
Click the button Stop (2). With this, the CAN connection is deactivated! The reaction time is dependant on the
timeout configuration.
