A very powerful method utilising delays with a multiple loudspeaker system is
to integrate the delay into the crossover such that one multitap delay will
provide all the facilities for one channel of a sound system. The BSS FDS-360
Electronic Crossover has built into it a special interface which will allow
interconnect of either the TCS-803 or the TCS-804 (See Figure 17.2). For
example, two TCS-803 units will then provide all the time correction needed
to correctly align a full four way stereo sound system; a single TCS-804 unit
will provide all the time correction needed to correctly align a stereo three
way system.
A special interface connector is available to assist in the connection of the
delay unit to the FDS-360 rear barrier strip (See Figure 14.3).
Fig 14.1 One Delay per
Channel
Applications
Fig 14.2 FDS-360 and
TCS-80X Integration
