21.0 Specifications
Input section: 10k ohm electronically balanced, +2-dBu maximum input level via XLR 3-31
or equivalent.
Output section: Electronically balanced and floating, capable of driving +20dBu into 600ohms
or greater via XLR 3-32 or equivalent.
Conversion method: Dynamic floating window PCM.
Frequency Response: ±0.5dB, 20Hz to 20kHz.
Dynamic Range: Typically 105dB, no pre-emphasis.
Distortion: ≤0.03% 20Hz - 20kHz at +10dBu level.
Group Delay Dev: ±7µS from 20Hz to 20kHz.
Stereo Sync: ±0.5µS.
User Memory Type: EEPROM. No batteries are required.
Delay Range - Stereo: 75µS - 650mS. (1.3 seconds Optional).
Mono: 75µS - 1.3S. (2.6 seconds Optional).
Minimum Step Size: 10µS (3.4mm at 21°C)
Input Level
TCS-804: +10dBu, ±10dB adjustable by level control.
TCS-803: -9 to +20dBu, digitally adjustable in 1dB steps.
Output Level
TCS-803: ±10dB adjustable by level control.
TCS-804: ±6dB digitally adjustable in 1dB steps.
Temperature: -19°C to +44°C manual entry or automatic with probe.
Remote pgm Select: 9 Pin submin D connector, 3 x 4 contact closure matrix for selection of 12
programs.
MIDI: IN, THRU, OUT 5 Pin 180° DIN connector.
Temperature Probe: 0.25" RTS jack socket for BSS probe.
