Technical Specifications
4
ekr CON 600, ekr CON 600 net – Application with Wide Array Edge Sensors 17/39
Dimensions [mm]
= Fixing dimensions
Measuring range M
Center of measuring range
600 mm cable
(connection to the
connection box)
Operating range
Fig.5: Dimensions of the infrared wide array edge sensors IR SEN 400 ... 409
Sensor Dimension
A B M O P T U W X Y Z
IRSEN400 67
106 30
18
10
38 77
95 116
18 5
IRSEN401 130 81 101 140
IRSEN402 67
136 60
18 38 77
127 146
IRSEN403 130 81 101 140
IRSEN404 67
251 162
18 38 77
228 261
IRSEN405 130 81 101 140
IRSEN406 67
373 284
18 38 77
355 383
IRSEN407 130 81 101 140
IRSEN408* 67
556 467
18 38 83
533 572 21 8
IRSEN409* 130 81 101 146
* in preparation
