BST ekr CON 600 net Installation And Operating Manual

4
Technical Specifications
16/39 ekr CON 600, ekr CON 600 net – Application with Wide Array Edge Sensors
4.2 Infrared Wide Array Edge Sensors IR SEN 400 ... 409
IRSEN…
400 401 402 403 404 405 406 407 408* 409*
Fork width
38
mm
101
mm
38
mm
101
mm
38
mm
101
mm
38
mm
101
mm
38
mm
101
mm
Measuring range 30mm 60mm 162mm 284mm 467mm
Min. web width 11mm
Linearity ≤ 0.7%
Supply voltage From the controller (24V⎓ ±10%)
Light emitter wave length 870nm
Output signal BST CAN bus
Polarity reversal protection (supply) yes
Operation display LED (bicolour)
Electrical connection M8 plug, 4-pin (at the connection box)
Ambient temperature
during operation
0 to +75°C
Storage temperature 0 to +75°C
Protection category IP40
Noise emission <70dB
Housing dimensions See dimensional drawing
RoHS conformity yes
* in preparation
