Troubleshooting
11
ekr CON 600, ekr CON 600 net – Application with Wide Array Edge Sensors 37/39
11 Troubleshooting
WARNING
Danger to life and assets caused by incorrect rectification of mal-
functions!
►
Only allow qualified personnel instructed by BST service staff or
authorized personnel to rectify malfunctions.
►
Only rectify malfunctions using the following measures or
follow the instructions of BST customer service.
►
Observe all safety instructions in the chapter Maintenance and
cleaning, see Safety Instructions, page 35.
Typical faults with their possible causes and measures for elimina-
tion are specified in the following.
►
For further information, please contact BST Customer Services,
address see Customer Services.
Fault
Possible causes Measures for eliminating the fault
An exclamation mark is shown in the display in the symbol of an
edge senor.
The web edge to be scanned is not detected by the
wide array edge sensor.
►
Perform material setup. See Performing the
Material Setup, page 32.
The web edge to be scanned is located outside the
measuring range of the wide array edge sensor.
►
Correct the position of the wide array edge
sensor across the web running direction.
