7. APPENDIX
7.1 SPECIFICATIONS
MODEL 3300 ELSD SPEC
IFICATIONS
Light Source:
Laser diode with collimating
optics, 650nm, max output
less than 30mW, Class IIIB
Product Class:
Class 1 laser product
Detector Element:
Silicon photodiode
Temperature Range:
Ambient to 120°C in 0.1°C
increments
Nebulizer Gas:
Up to 4.0L/min, nitrogen
preferred, 65psig min.
pressure, 80psig max
pressure
Mobile Phase Flow Rate:
50uL-3.0mL/min
Analog Outputs:
Selectable for either 0-1V or
0
-
10mV full scale
Communications:
Remote Inputs:
TTL/Contact
closure-Autozero, Gas
Shutoff, Start, Standby
Outputs: Contact closure--
Fault Relay, External Output;
RS232, USB (Device), USB
(Host), Ethernet
Operating Parameter
Selection & Display:
Windows

-Based Graphical
LCD with alphanumeric
keypad
Pow
er Requirements:
120/240V, 50/60Hz, 5A
Dimensions:
10.0" H x 10.25" W x 19.0" D
(25.4cm H x 26.0cm W x
48.3cm D)
Weight:
30 lbs (13.6 kg)
Environmental Operating
Temperature:
15 to 40˚C
Relative Humidity:
10 – 90%, Non-Condensing
7.2 REPLACEMENT PARTS
MODEL 3300 ELSD REPL
ACEMENT PARTS
Part No.
Qty.
Description
145136931
142112995
142112993
142107259
142106694
142107268
142112992
142112880
142110773
145126955
142110623
142111502
142111503
142112997
142112990
143112777
142108384
142112994
11593900
142112991
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3300 ELSD Accessory Kit
(includes all parts listed above the divider)
Signal Cable
Power Cord, 110V
Open-End Wrench, 3/8" x 7/16"
Open-End Wrench, 1/4" x 5/16"
Ball Driver, 3/32"
Ball Driver, 7/64"
Drift Tube Cleaning Brush
PEEK Tubing, 1/16" o.d. x .005" i.d., 10’
SofGrip Fittings, 10/pk
Gas Tubing, 10’
1/8" Brass Nut
1/8" Brass Ferrule
Drain Tubing, 5'
Clamp for Drain Tubing
Exhaust Tubing, 20’
Exhaust Adapter
Fuse, 5 Amp
Model 3300 ELSD Operating Manual
14 Pin Terminal Block
142113967
142113968
142114811
142107480
142107476
142107511
148606365
142113956
142113954
1
1
1
1
1
1
1
1
1
Nebulizer
Nebulizer Wear Band
Chemraz O-ring for Nebulizer
.25 x .79 Aperture
.31 x .74 Aperture
.36 x .74 Aperture
Gas Filter
Front Service Door
Inlet Gas Fitting
