Technical data
6.9. Electrical data
Connections   CableglandM16x1.5,wrenchsize19
(clampingarea4...8mm)
with screw terminals
forcablecross-sections0.14...1.5mm²
Circularplug-inconnectorM12x1,8-pole
Supplyvoltage
 Pilotvalve   24VDC±10%,residualripple10%
UL:NECClass2,24VDC,1W
Power consumption
ofpilotvalve  1W
Micro switch For maximum current load see table
  Variantforsafetyextra-lowvoltage(0...48VAC/DC)
24V 48V
resistiveloadandsemi-conductor
load
2AAC
2ADC
2AAC
2ADC
inductiveload(cosϕ=0,3) 2AAC
2ADC
1,5AAC
1ADC
  Variantforlowvoltage(50...250VAC/DC)
1)
110/127V 220/240V
resistiveloadandsemi-conductor
load
2AAC
0,4ADC
2AAC
0,2ADC
inductiveload(cosϕ =0,3) 0,5AAC
0,2ADC
0,2AAC
0,1ADC
1) When used in the UL area, voltage and current are limited to 125 V AC
1 A. Also both micro switches must be fed from the same power supply.
Proximity switches
    3-wirePNP10...30VDCmax.100mAper
proximity switch
2-wire24VDCnormallyopen10...30VDC
 max.100mA,min.3mAperproximityswitch,
 Voltagedrop<5VResidualcurrent<0,6mA
2-wireNAMUR8,2VDC,1,2/2,1mA
 (actuated/notactuated)UL:NECClass2
 Positionfeedback(option)
    Protectionclass3acc.toDINEN61140(VDE
0140-1):
2microswitches0...48VAC/DC,
2initiators10...30VDC,normallyopencontactPNP
(3-wire),
2initiators10...30VDC,normallyopencontact
(2-wire),
2initiatorsNAMUR(8.2VDC)(2-wire)
    Protectionclass2acc.toDINEN61140(VDE
0140-1):2microswitches50...250VAC/DC
