6 Electrical Connection
DANGER
Live wires.
Risk of electrical shock.
● Electrical installation work must only be executed by qualified personnel.
CURRENT PROTECTION OF THE CUSTOMER INSTALLATION:
DANGER
Missing current protection.
Risk of electrical shock.
● Current protection according to EN 60204-1 must be insured by the customer on its installation.
● The electrical installation must comply with the applicable national and international standards.
NOTICE
Electromagnetic compatibility.
● Make sure that the motor of the machine will not be affected by electric or electromagnetic dis-
turbance from the mains, if necessary seek advice from Busch.
● Make sure that the EMC of the machine is compliant with the requirements of your supply net-
work system, if necessary provide further interference suppression (EMC of the machine, see EU
Declaration of Conformity [➔37] or UK Declaration of Conformity [➔38]).
6.1 Machine delivered with a Variable Speed Drive
NOTICE
Incorrect connection.
Risk of damage to the variable speed drive!
● The wiring diagrams given below are typical. Check the connection instructions/diagrams.
● Make sure that the power supply for the drive is compatible with the data on the nameplate of
the variable speed drive.
● If the machine is equipped with a power connector, install a residual current protective device to
protect persons in case of isolation default.
● Busch recommends installing a type B residual protective device suitable for the electrical in-
stallation.
● If the variable speed drive is not equipped with a lockable disconnect switch, provide it on the
power line so that the machine is completely secured during maintenance tasks.
● Provide an overload protection according to EN 60204-1.
● Connect the protective earth conductor.
