Installation | 5
Instruction Manual MINK MV 0500-0600 B_EN_en 11 | 40
5.2 Connecting Lines / Pipes
WARNING
Rotating Parts.
Risk of severe injury!
● Do not operate the machine without suction / discharge connection installed.
● Remove all protective covers before installation.
● Make sure that the connection lines cause no stress on the connection of the machine; if neces-
sary use flexible joints.
● Make sure that the line size of the connection lines over the entire length is at least as large as
the connections of the machine.
In case of long connection lines, it is advisable to use larger line sizes in order to avoid a loss of effi-
ciency. Seek advice from your Busch representative.
NOTICE
Flow of potential condensate from the piping to the vacuum pump.
Risk of damage to the machine!
● Make sure that the vacuum pump suction and exhaust connection pipes are installed in such a
way as to prevent the flow of potential condensate from the piping to the vacuum pump.
● Busch recommends the use of the optional horizontal inlet filter and the water separator to col-
lect the condensate and prevent it from flowing into the pump.
5.2.1 Suction Connection
NOTICE
Ingress of foreign objects or liquids.
Risk of damage to the machine!
If the inlet gas contains dust or other foreign solid particles:
● Install a suitable filter (5micron or less) upstream from the machine.
Connection size(s):
– G3”
Depending on the specific configuration ordered, other connection dimensions may apply.
