3 | Transport
8 | 40 Instruction Manual MINK MV 0500-0600 B_EN_en
3 Transport
WARNING
Suspended load.
Risk of severe injury!
● Do not walk, stand or work under suspended loads.
WARNING
Lifting the machine using the motor eye bolt.
Risk of severe injury!
● Do not lift the machine using the eye bolt fitted to the motor. Only lift the machine as shown.
● To find out the weight of the machine, refer to the chapter Technical Data [➔35] or the name-
plate (NP).
● Make sure that the eye bolt(s) (EB) is/are in faultless condition, fully screwed in and tightened by
hand.
Description
1 Use both eye bolts!
● Check the machine for transport damage.
If the machine is secured to a base plate:
● Remove the machine from the base plate.
