RF Settings
Frequency MHz
Power (model dependent)
100% Modulation 10-250kHz
MPX Source Internal/MPX Input 1/MPX Input 2
RF Mute on/off
FSK on/off
FSK ID
Power Scheduler
Power W
Start time hh:mm
Finish time hh:mm
Enable on/off
Current time Select to se
Synchronisation
External 10MHz ref off/on
Internal 10MHz trim +/- 10ppm
1pps Synch off/on
Audio Delay 0-20mS
Pilot phase 0-359 degrees
Audio Settings
Input source Analog/Digital/Tuner
Analog ref level 0-24dBu
Digital ref level -30 – 0dBFS
Audio Processor on/off
Preemphasis off/50/75uS
Processing Preset List of presets
Audio mode Stereo/Mono L+R/Mono L/Mono R
/Swap L/R
Gain Trimming
Audio Trim 0-1dB
Audio Right Trim 0-1dB
MPX
Inputs/Outputs
MPX1 In Level 0-12dBu
MPX2 In Level 0-12dBu
MPX1 Out Source MPX/Pilot/RDS/Ext MPX 1/Ext MPX 2
MPX1 Out Level 0-12dBu
MPX2 Out Source MPX/Pilot/RDS/Ext MPX 1/Ext MPX 2
MPX2 Out Level 0-12dBu
Trimming
Tuner MPX Level Trim 0-1dB
MPX1 In Trim 0-1dB
MPX2 In Trim 0-1dB
MPX1 Out Trim 0-1dB
MPX2 Out Trim 0-1dB
