12 Operating Instructions Edition 5/06
Operating panel
A2+/A4+/A6+/A8+
4.2 Functions of the operating panel during printing
4.2.1 Symbol indicators
The symbol indicators shown in the following table can appear on the status line of the screen, depend-
ing on the configuration of the printer. They inform you of the current status of the printer at a glance. For
configuration of the status line, see the “Configuration Instructions“.
Tab. 2:Indicator symbols during printing
4.2.2 Power-Save mode
If the printer is not used for some time, it switches to Power-Save mode automatically.
The display shows the graphic and button illumination is switched off.
To exit Power-Save mode:
Press any button on the navigator pad.
Symbol Meaning
Time
Date
Ribbon supply status
WLAN field strength
Ethernet status
Printhead temperature
PPP credit
User memory
Input buffer
Printer receiving data
