A2+/A4+/A6+/A8+
Operating panel
Edition 5/06 Operating Instructions 13
4.2.3 'Ready' mode
The printer is ready and can receive data.
The display shows the text Ready and the configured symbol indicators, such as the time and date
.
Tab. 3:Functions in Ready mode
4.2.4 'Printing Label' mode
The printer is carrying out a print job. Data transfer for a new print job is possible in 'Printing' mode. The
new print job starts once the preceding job is completed.
The display shows the text Printing Label and the number of the printed label within the print job.
Tab. 4:Functions in Printing Label mode
4.2.5 'Pause' mode
The print job has been interrupted by the operator.
The display shows the text Pause and the symbol .
Tab. 5:Functions in Pause mode
Button Label Function
menu illuminates go to offline menu (see “Configuration Instructions“)
feed illuminates advances an empty label
pause illuminates
once a print job is complete
repeat printing of last label
cancel illuminates clear print buffer,
repeated printing of the last label is then not
possible
Button Label Function
pause illuminates pause print job,
printer switches to Pause mode
cancel illuminates press briefly→ cancel current print job
press and hold→ cancel current print job and
delete all print jobs
Button Label Function
pause illuminates continue print job,
printer switches to Printing Label mode
cancel illuminates press briefly→ cancel current print job
press and hold→ cancel current print job and
delete all print jobs
