CAB A4 Service Manual

27
Serviceanleitung / Service Manual / / /
Geräteliste
Name Beschreibung
CPU A3, #044025151110
PCB-Rev. 9, FPGA-Rev. 10
TPH 203 dpi, 832 dots
SLOT Ethernet 10/100 MBit/s
#111034425201, Rev. 1.00
MAC: 00:02:E9:00:32:82
USB [1] Cypress Semiconductor/USB 1.1 4-port Hub
[0] Full Rev. 0.01
Mfr: 04B4, Class: 09/00, Protocol: 00, Phase: 20/0
USB [2] cab/Service-Key
[1/4] Low #7-5037793, Rev. 1.05
Mfr: 0985, Class: FF/00, Protocol: FF, Phase: 20/4
USB [3] cab/Frontpanel
[1/1] Full Rev. 1.02
Mfr: 0985, Class: FF/01, Protocol: 00, Phase: 20/1
USB [3] cab/CompactFlash
[1/1] Full Rev. 1.02
Mfr: 0985, Class: FF/02, Protocol: 00, Phase: 20/8
Bild 7 Geräteliste Deutschland mit gestecktem
Serviceschlüssel
Fig. 7 United Kingdom Device List Printout with
Service Key inserted
Device list
Name Description
CPU A3, #044025151110
PCB-Rev. 9, FPGA-Rev. 10
TPH 203 dpi, 832 dots
SLOT Ethernet 10/100 MBit/s
#111034425201, Rev. 1.00
MAC: 00:02:E9:00:32:82
USB [1] Cypress Semiconductor/USB 1.1 4-port Hub
[0] Full Rev. 0.01
Mfr: 04B4, Class: 09/00, Protocol: 00, Phase: 20/0
USB [2] cab/Service-Key
[1/4] Low #7-5037793, Rev. 1.05
Mfr: 0985, Class: FF/00, Protocol: FF, Phase: 20/4
USB [3] cab/Frontpanel
[1/1] Full Rev. 1.02
Mfr: 0985, Class: FF/01, Protocol: 00, Phase: 20/1
USB [3] cab/CompactFlash
[1/1] Full Rev. 1.02
Mfr: 0985, Class: FF/02, Protocol: 00, Phase: 20/8

CAB A4 Specifications

General

Printer Type	Thermal transfer / direct thermal
Interfaces	USB, Ethernet, RS232
Label Thickness Range	0.05 mm - 0.25 mm
Memory	8 MB Flash
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	+5°C to +40°C
Print Resolution	203 dpi
Humidity Range	10-85% non-condensing
