5 Test Functions
5.3 Status Print
The Status print function prints a test image containing information on the conguration and status of the printer.
The printout occurs using the heat level and print speed specied in the Setup > Print param. menu.
i
Notice!
The printout occurs without taking the label gaps into consideration. This is why endless media are most
suitable for this purpose.
 Insert printable medium (labels, endless paper) which extends across the entire printing width.
 If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
 Start Ofine menu.
 Select Test > Status print.
The printout can be cancelled with
.
Status print
Fri Sep 23 09:46:51 2011
EOS1/300
Firmware V4.02 (Sep 21, 2011) - #170110417590
Local settings
Language English
Country Germany
Timezone UTC+1 (Berlin,Paris)
Daylight saving EU
Date 06.09.2011
Time 10:53:12
Keyboard Germany
Machine param.
Printhead pos. X 0,0mm
Printhead pos. Y 0,0mm
Tear-off pos. 0,0mm
Cutter
Cut position 0,0mm
Cutting depth 0
Backfeed position 0,0mm
Brightn. LCD 8
Contrast LCD 0
Volume Speaker 2
Time Powersave 5min
Cleaning interval Off
Debug mode Off
Print param.
Heat level 0
Print speed 30mm/s
Transfer print Ein
Warn level ribbon 32mm
Label sensor Gap Sensor
Extrapolate pos. Off
Tear-off mode On
Backfeed smart
Error-Reprint On
Reprint option On
Protocol error On
Barcode error On
Width ASCII dump Automatic
Interfaces
Network
Ethernet
DHCP Off
IP-Adresse 192.168.9.55
Maske 255.255.255.0
Gateway Off
WLAN
Access-Point -
DHCP Off
IP-Adresse -
Maske 255.255.255.0
Gateway Aus
RawIP-Port 9100
LPD On
LPD queue name lp
Time service NTP
Time server -
Network error Off
RS-232
Baud Rate 115200
Handshake RTS/CTS
Default storage USB Memory
Character set Windows 1252
Status line
Clock On
Date sheet On
Date/time digital Off
Temperature Off
Ribbon supply Off
Cutter Off
Ethernet status On
WLAN Off
Bluetooth Off
Data transfer On
Security
Security Off
Printer info
Operative time
Total 498h 01min
Service @ 430h 33min
Number of labels
Total 1451
Service @ 1240
Thermal transfer
Total 89.204m
Service @ 77.330m
Thermal direct
Total 4,027m
Service @ 4,027m
Fig. 11 Status print
Parameters marked italic are only printed when the printer is equipped with the respective optional
assembly or when the service key is inserted
