26 26
5 Test Functions
5.4 Font List
The Font list function prints the most important parameters of the fonts available in the printer in tabular form.
The table contains both the original fonts in the printer and other fonts loaded into the printer. The printout occurs
using the heat level and print speed specied in the Setup > Print param. menu.
Notice!
The printout occurs without taking the label gaps into consideration. This is why endless media are most
suitable for this purpose.
Insert printable medium (labels, endless paper) which extends across the entire printing width.
If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
Start Ofine menu.
Select Test > Font list.
The printout can be cancelled with
.
Font list
Fri Sep 23 11:27:49 2011
EOS1/300
Firmware V4.02 (Sep 21, 2011) - #170110417590
Nr. Name Type Description
-1 _DEF1 Bitmap Default Font 12x12 dots
-2 _DEF2 Bitmap Default Font 16x16 dots
-3 _DEF3 Bitmap Default Font 16x32 dots
-4 OCR_A_I Bitmap OCR-A Size I
-5 OCR_B Bitmap OCR-B
3 BX000003 TrueType Swiss 721
5 BX000005 TrueType Swiss 721 Bold
596 BX000596 TrueType Monospace 821
1000 GHEI21M TrueType AR Heiti Medium GB-Mono
1010 GARUDA TrueType Garuda
Fig. 12 Font list
Column Meaning
No. ID number of the font required for programming (command T).
Name Name with which the font is saved internally.
Type Type of font generation. It provides information on the variability of the font and is important when
programming (command T).
Description Explanations of the font: size, font family. The printout occurs in the appropriate font.
Table 12 Parameters of the Font list
