CAB Hermes+ Service Manual

33
6.2 Hardware Faults
Error message Cause Fault recovery
ADC malfunction
Fault on the PCB CPU Replace the PCB CPU
FPGA malfunction
Fault on the PCB CPU Replace the PCB CPU
Invalid setup
Fault on the PCB CPU Replace the PCB CPU
Voltage error
V
BAT
Voltage of the battery on the
PCB CPU is too low
Replace the PCB CPU
V
MOT
Motor voltage is too low Check motor voltage at the measurement point V
mot
 8 on page 35:
• Voltage too low:
Replace the power supply unit
• Voltage is correct:
Replace the PCB CPU
24 V
24 V too low Check voltage at measurement point +24V
 8 on page 35:
• Voltage too low:
Replace the power supply unit
• Voltage is correct:
Replace the PCB CPU
24 V ext.
24 V at peripheral connection
too low
Disconnect peripheral device
• Fault still exists:
Replace the PCB CPU
• Fault remedied:
Repair or replace peripheral device
Table 4 Hardware faults
6 Troubleshooting and Error Treatment

CAB Hermes+ Specifications

General

Power Supply	100 - 240 V AC, 50/60 Hz
Print Technology	Thermal Transfer
Resolution	203 dpi
Interfaces	USB, Ethernet
Display	LCD
Memory	8 MB RAM
Supported Barcodes	1D and 2D barcodes
