6 Cleaning
6.1 Cleaning Information
Danger!
Risk of death via electric shock!
Disconnect the print module from the power supply before performing any maintenance work.
The print module requires very little maintenance.
It is important to clean the thermal printhead regularly. This guarantees a consistently good printed image and plays a
major part in preventing premature wear of the printhead.
Otherwise, the maintenance is limited to monthly cleaning of the device.
Attention!
The print module can be damaged by aggressive cleansers.
Do not use abrasive cleaners or solvents for cleaning the external surfaces or modules.
Removedustandpaperufffromtheprintareawithasoftbrushorvacuumcleaner.
The cover of the print module can be cleaned with a standard cleanser.
6.2 Cleaning the Rollers
Accumulations of dirt on the print and transport rollers may impair the media transport and the print quality.
Lift the printhead, open the transport systems.
Remove labels and transfer ribbon from the print module.
Remove deposits with roller cleaner (Part No. 9200051) and a soft cloth.
If a roller is badly soiled or appear damaged, replace it Service Manual.
6.3 Cleaning the Printhead
Cleaning intervals: direct thermal printing - every media roll change
thermal transfer printing - every ribbon roll change
Substances may accumulate on the printhead during printing and adversely affect printing, e.g. differences in contrast
or vertical stripes.
Attention!
Printhead can be damaged!
Do not use sharp or hard objects to clean the printhead.
Do not touch protective glass layer of the printhead with ngers.
Attention!
Risk of injury from the hot printhead.
Ensure that the printhead has cooled down before starting cleaning.
Lift the printhead.
Remove labels and transfer ribbon from the printer.
Clean printhead surface with a cotton swab dipped in pure alcohol.
Allow printhead to dry for 2–3 minutes before commissioning the printer.
