CAB PX Series User Manual

23
8.2 Device Dimensions
Fig. 15 Device dimensions
Dim. Designation Dim. in mm
PX4 PX4.3 PX6
dpi 203 300 600 203 300 203 300
I Distance printhead - peel-off edge 14,4
J
Distance 1st heating point - material edge L
R
2,0
3,8
2,0
2,0
2,0
2,1
2,0
3,7
2,0
-0,7
0,4
0,4
3,1
3,1
K
Print width L
R
104,0
104,0
105,7
105,7
105,6
105,6
104,0
104,0
108,4
107,7
168,0
168,0
162,6
162,6
SX
Distancegap/reectivesensor-
materialedge,i.e.permissibledistanceofreex
or cut-out marks to the material edge
4 - 60
SY
Distancegap/reectivesensor-
printhead
94,5
Table 9 Device dimensions
8.3 Reex Mark Dimensions
Fig. 16 Reexmarkdimensions
Dim. Designation Dim. in mm
A Label distance > 2
L
Widthofreexmark > 5
M
Heightofreexmark 3 - 10
X Distance mark - material edge 4 - 60
Z Distance virtual label front edge - actual label front edge
 Adjust software settings
0 up to A /
recomm. : 0
• Reexmarksmustbeonthebacksideofthematerial(liner).
• Labelsensorforreexmarksonthetopsideonrequest.
• Specicationisvalidforblackmarks.
• Recognition of colored marks may fail.  Preliminary tests are needed.
Table 10 Reexmarkdimensions
