2 Installation
2.2 Unpacking and Setting-up the Print Module
Lift the print module out of the box.
Check print module for damage which may have occurred during transport.
Check delivery for completeness.
Attach the print module to the prepared construction using four screws M5x20
(Mounting dimensions 9 on page 25).
Remove foam transportation safeguards at the printhead and the backfeed system.
Contents of delivery:
• Print module
• 4 Screws M5x20
• Power cable
• USB cable
• Operator's Manual
• DVD with label software, Windows driver and documentation
Notice!
Please keep the original packaging in case the print module must be returned.
Attention!
The device and printing materials will be damaged by moisture and wetness.
Set up print modules only in dry locations protected from splash water.
2.3 Connecting the Device
Thestandardavailableinterfacesandconnectorsareshowningures4and5.
2.3.1 Connecting to the Power Supply
The print module is equipped with a wide area power unit. The device can be operated with a supply voltage of
230 V~/50 Hz or 115 V~/60 Hz without adjustment.
1. Check that the device is switched off.
2. Plugthepowercableintothepowerconnectionsocket(24/g.4/5).
3. Plug the power cable into a grounded socket.
2.3.2 Connecting to a Computer or Computer Network
Attention!
Inadequate or no grounding can cause malfunctions during operations.
Ensure that all computers and cables connected to the print module are grounded.
Connect the print module to a computer or network by a suitable cable.
For details of the I/O interface Interface Description.
FordetailsofthecongurationoftheotherinterfacesCongurationManual.
2.4 Switching on the Device
When all connections have been made:
Switchtheprintmoduleonatthepowerswitch(7/g.2).
The print module performs a system test, and then shows the system status Ready in the display.
If an error occurs during the system test, the symbol
and type of error are displayed.
