Cafection Encore VENTI - Main Board PCB Description

ENCORE VENTI Rev. 3 2021-10
www.cafection.com 800-561-6162
14
SERVICE & INSTALLATION MANUAL for Cafection's Encore Venti
3.6.1 Main board (PCB) Description
Interactive Switches and Buttons
1. Reset Button (Red)
Pressing this button will reset the
main board, not the computer
screen. For example, pressing
the red reset button will stop the
process of a product being made
but will not restart the computer
screen.
2. SW2 Setup Button (White)
This button gives access to the
parameters of the machine and
products through Service mode (see
section6.2 for details).
3. SW3 Calibration Button
This button allows touch screen
calibration. If the screen is not
responding well to finger pressure, it
might need recalibration. Press this
button and follow instructions on the
screen.
4. SW6 Factory Tools Button
Tools for Cafection only.
5. Reset Settings
PressSW1, SW5 and SW4 one after
the other. A reset pop-up window
will be displayed on the screen.
Contact Cafection’s Technical
Support team to get a confirmation
number.
Green LEDs
The green LEDs light up to indicate the following
statuses:
DS1 Power5V OK
DS13 Brew group out of park position
DS14 Filter paper roll detected
DS15 Low water level
DS17 Cup is present (optional cup sensor)
DS18 Water detected in the overflow tray
Red LEDs
The red LEDs light up to indicate
the following parts are in use:
24V DC Outputs:
DS2 Whip motor (coffee)
DS3 Ingredients motor (coffee # 1)
DS4 Ingredients motor (coffee # 2)
DS5 Ingredients motor (coffee # 3)
DS6 Ingredients motor (soluble # 1)
DS7 Ingredients motor (soluble # 2)
DS8 Ingredients motor (soluble # 3)
DS22 Hot water valve (coffee)
DS29 Hot water valve (soluble #1)
DS30 Hot water valve (soluble #3)
DS31 Hot water valve (soluble #2)
DS32 Hot water dispensing valve
DS33 Whip motor (soluble #1)
DS34 Whip motor (soluble #2)
DS35 Whip motor (soluble #3)
DS36 Coms activity between touch screen
and brewer
DS38 Power24V DC OK
120V AC Outputs:
DS9 Brewer motor
DS10 Water inlet valve
DS11 Coffee bean grinder
Reference Drawings
