SERVICE & INSTALLATION MANUAL for Cafection's Encore Venti
Initial Setup
4.6 Overflow tray installation
The overflow tray will detect the water flood and an error
message will be displayed.
1. Screw the overflow drip tray support under the base of the
brewer using the 2 screws included.
2. Take out the 2 wires with connectors found inside the
brewer using the chute hole and connect them to the
2connectors of the overflow drip tray.
3. Put the connected overflow drip tray on its support.
4.7 Drip Tray Installation
1. Place the drip tray support in position on the door using its hooks.
2. Use the two screws (pre-screwed in the door panel) to lock the drip tray support in place.
3. Install the drip tray on the support.
4. Install the grill on the drip tray.
The drip tray must be secured by the two support
front retaining pins.
Drip tray
support
Drip tray
grill
Drip tray
