User's Guide — 19
.5d
DIAMETER
0.5 INCH
7. Calculate RPM:
R
RPM
4584.
8. Show tabular Cut Speed:
R
CUT SPEED
/MIN 600. FEET
9. Now, change the Depth of Cut to 0.1" and nd new RPM
and tabular Cut Speed:
.1gN (DOC)
DEPTH OF CUT
0.1 INCH
R
RPM
6875.
R
CUT SPEED
/MIN 900. FEET
RPM – End Milling
1. Clear the calculator:
OO
0.
2. Set Process to End Milling:
2P
END MILLING
2.
3. Set Tooling to Carbide:
2L
CARBIDE TOOL
2.
