52 — Machinist calc
®
Pro 2
16t
THREAD SIZE
2A 0.375 - 16 INCH
4. Enter the Wire Size**:
.04gS (Wire Size)
STORED WIRE SIZE
0.04 INCH
5. Find the Minimum 3-Wire Measurement:
gR (3W Measure)
3-WIRE MEASURE
MIN 0.395 INCH
6. Find the Maximum 3-Wire Measurement:
R
3-WIRE MEASURE
MAX 0.399 INCH
7. Find the Minimum Pitch Diameter:
R
PITCH DIAMETER
MIN 0.329 INCH
8. Find the Maximum Pitch Diameter:
R
PITCH DIAMETER
MAX 0.333 INCH
R
STORED WIRE SIZE
0.04 INCH
** If no Wire Size is entered, the calculated Ideal Wire Size will be
used to nd the 3-Wire Measurement.
Pitch Diameter – Known 3-Wire Measurement and Wire Size
measurement.
using a 0.040 Inch wire:
OO 0.
(cont'd)
