User's Guide — 29
(cont'd)
Feed per Tooth – Based on Feed Rate, RPM and # of Teeth
OO
0.
1. Enter the Feed Rate:
12.8I
FEED/MINUTE
12.8 INCH
2. Enter the Number of Teeth:
4gI (#Teeth)
NUMBER OF TEETH
4.
3. Enter the RPM:
775R
RPM
775.
4. Calculate the Feed per Tooth:
T
FEED/TOOTH
0.004 INCH
Feed per Tooth – Face Milling
g*
ALL CLEARED 0.
1. Select the Process:
1P
FACE MILLING
1.
2. Select the Tool:
